Specifications:
TABLE SIZE ............................ 70.87" X 28.35"
MAX LOAD CAPACITY ........................... 4400 LBS
X-AXIS TRAVEL .................................. 60.63"
Y-AXIS TRAVEL .................................. 29.92"
Z-AXIS TRAVEL .................................. 25.98"
SPINDLE NOSE TO TABLE .................. 7.81" ~ 33.87"
SPINDLE CENTER TO COLUMN ....................... 31.5"
SPINDLE SPEEDS ( 2-RANGES) .................. 6000 RPM
SPINDLE MOTOR .................................. 25 HP
TOOL CHANGER CAPACITY ..................... 36 STATIONS
SPINDLE TAPER .................................. CAT#50
TOOL CHANGER TIME .............................. 6 SEC.
MAXIMUM TOOL LENGTH ............................ 15.75"
MAXIMUM TOOL DIAMETER .......................... 7.87"
MAXIMUM TOOL WEIGHT ............................ 44 LBS
FEEDRATE X/Y/Z ................................. 741 IPM
RAPID TRAVERSE X/Y/Z ........................... 630 IPM
CUTTING FEEDRATE ............................... 394 IPM
FLOOR SPACE .................... 170" X 160" X 127" TALL
MACHINE WEIGHT .............................. 28,500 LBS
EQUIPPED WITH:
- FANUC 31I MODEL A CNC CONTROL
- 36 TOOL CHANGER
- REAR DISCHARGE CHIP CONVEYOR
- SPINDLE CHILLER SYSTEM
- 6,000 RPM 50 TAPER BIG PLUS
Traditional box ways is used for all axes to give high accuracy,
Rigidity over the long term.
