Drilling capacity: steel 2 1/4"
cast iron 2-5/8"
Tapping capacity: steel 2"
cast iron 2-3/8"
Boring capacity: steel 5"
cast iron 7-3/8"
Column diameter 15-3/8"
Minimum/Maximum distance, face of column to 14-9/16" ~ 63"
centerline of spindle 22-1/4" ~ 70"
Minimum/Maximum distance, column center to 17-1/8" ~ 61"
Height of base 9-1/16"
Height of column 117-3/4"
Maximum height from spindle head to floor 131"
Vertical travel of spindle in head 11-3/4"
Taper in spindle #5 Morse
Spindle diameter 3-1/8"
Quill diameter 4-1/8"
Vertical traverse of arm on column 32-7/8"
Horizontal traverse of head on arm 48-7/16"
(12) Spindle speeds 30 ~ 1,580 RPM
(12) Feeds .0025 ~ .045 IPR
Maximum height over column cap 117"
Equipped with:36" Wide x 19-7/8" Deep x 19-3/4" High t-slotted
box table
Hydraulically actuated pre-selection of next spindle speed while
spindle is running
Hydraulically actuated clamping of arm on column and head on arm
Motorized raising/lowering of arm on column
Automatic tool ejector
Self-contained coolant system with 1/8 H.P. pump motor
1 H.P. hydraulic pump motor
2 H.P. arm elevation motor
7.5 H.P. 3/60/220-440 volt spindle drive motor and electrical
controls
Machine is wired for 220 volt operation.
Approximate Weight: 8,000 Lbs.
Approximate Shipping Dimensions: 94" L-R x 38" F-B x 122" H
Condition: Very Good
(F.O.B. Truck, Hauppauge - Long Island, NY)
